3J Finger power chuck

Inquire Now Next

Product Details

Gripping at the end face and preventing deformation of workpieceSuitable for thin wall workpiece processing 2.The gripping compensating mechanism can grasp the irregularsurfaceworkpieces well

Product Size

Product Parameters

Model	Rotating Stroke (mm)	Claming Stroke(mm)	Jaw stroke(mm)	Clamping diameter(mm)		Max.D.B.pull kN(kgf)	Max.Clamping force kN(kgf)	Max.speed r.p.m	Moment of inertia mm	Weight kg	Matching cylinder	Max.pressure Mpa(kgf/cm²)
Model	Rotating Stroke (mm)	Claming Stroke(mm)	Jaw stroke(mm)	max	min	Max.D.B.pull kN(kgf)	Max.Clamping force kN(kgf)	Max.speed r.p.m	Moment of inertia mm	Weight kg	Matching cylinder	Max.pressure Mpa(kgf/cm²)
3J-05	12	8	2	53	25	7.5(765)	6.0(612)	4000	0.02	11	SH-100	1.0(10)
3J-06	12	8	2	79	55	9.0(918)	7.5(765)	4000	0.04	12	SH-100	1.2(12)
3J-08	12	8	2	106	75	18.0(1835)	16.5(1680)	3500	0.13	23	SH-100	2.5(25)
3J-10	12	8	2.5	150	119	18.0(1835)	16.5(1680)	3500	0.3	33	SH-100	2.5(25)
3J-12	12	8	2.5	200	169	18.0(1835)	16.5(1680)	3000	0.56	44	SH-100	2.5(25)

Model /Spec	A	B	C(H6)	D	F	G max	G min	J	J1	k	L	L1	M max	M min	N	P	Q	R	S	T	U
3J-05	135	86	110	82.6	40	75	55	25	9	M12x1.75	M10	15	56	36	20	M10	42.5	27	3-M6	50	-
3J-06	165	86	140	104.8	45	75	55	28	12	M16x2	M10	15	56	36	20	M10	57.5	40	3-M8	64	-
3J-08	210	90	170	133.4	56	80	60	38	16	M20x2.5	M12	18	71	51	25	M12	77.5	53.5	6-M8	104	20°
3J-10	254	95	220	171.4	56	75	55	38	16	M20x2.5	M16	24	71	51	25	M12	99.5	75.5	6-M8	140	20°
3J-12	304	95	220	171.4	56	75	55	38	16	M20x2.5	M16	24	71	51	25	M12	124.5	100.5	6-M8	190	20°
